Pressure Standard for Different Sizes Empty Aerosol Tin Cans

Home Blog

Pressure Standard for Different Sizes Empty Aerosol Tin Cans

Pressure Standard for Different Sizes Empty Aerosol Tin Cans
October 29, 2020

Different sizes of Empty Aerosol Tin Cans will be with Different Pressure Standard.

Pressure is one of the most important part of empty aerosol tin cans, different sizes of aerosol tin cans will be different pressure. As we known that, the GB normal pressure standard for Empty aerosol tin cans is 1.20Mpa for Deformation pressure, 1.40Mpa for Bursting pressure, the GB high pressure standard for Empty aerosol tin cans is 1.80Mpa for Deformation pressure, 2.00Mpa for Bursting pressure.  All the aerosol tin cans products must be reach the GB pressure standard to produce, which is the qualified products.

High pressure tin cansNormal pressure tin cans

Guangdong Sihai Iron-Printing and Tin-Making Co., Ltd can manufacture the empty aerosol tin cans sizes of Diameter 45mm, 52mm, 57mm, 60mm, 65mm, 70mm with Necked-In and Straight-wall types. The same sizes of empty aerosol tin cans will be with normal pressure and high pressure standard, we can use different thickness of tinplate to make cans, differnt sizes of cans can be with different thickness of tinplate for cans body and cans cones and cans domes.


Diameter(mm) Type Deformation Pressure(Mpa) Bursting Pressure(Mpa)
Printing Thickness(mm)
45mm Necked-In 1.45Mpa 1.65Mpa
CMYK colors & Inner coating 0.19mm for Body, 0.28mm for Cones & Domes
45mm Necked-In
1.80Mpa
2.00Mpa
CMYK colors & Inner coating
0.20mm for Body, 0.32mm for Cones & Domes
52mm Necked-In
1.45Mpa
1.65Mpa
CMYK colors & Inner coating
0.19mm for Body, 0.28mm for Cones & Domes
52mm Necked-In
1.80Mpa
2.00Mpa
CMYK colors & Inner coating
0.20mm for Body, 0.32mm for Cones & Domes
57mm Necked-In
1.45Mpa
1.65Mpa
CMYK colors & Inner coating
0.19mm for Body, 0.28mm for Cones & Domes
60mm Necked-In
1.35Mpa
1.45Mpa
CMYK colors
0.19mm for Body, 0.32mm for Cones & Domes
60mm Straight-Wall 1.45Mpa
1.65Mpa
CMYK colors
0.19mm for Body, 0.32mm for Cones & 0.35mm for Domes
65mm Necked-In
1.35Mpa
1.45Mpa
CMYK colors & Inner coating
0.19mm for Body, 0.32mm for Cones & Domes
65mm
Necked-In
1.80Mpa
2.00Mpa
CMYK colors & Inner coating
0.20mm for Body, 0.43mm for Cones & 0.43mm for Domes
65mm
Straight-Wall
1.35Mpa
1.45Mpa
CMYK colors & Inner coating
0.20/0.21mm for Body, 0.32mm for Cones & 0.35mm for Domes
65mm
Straight-Wall
1.80Mpa
2.00Mpa
CMYK colors & Inner coating
0.21mm for Body, 0.40mm for Cones & 0.40/0.43mm for Domes
70mm
Necked-In
1.35Mpa
1.45Mpa
CMYK colors
0.20/0.21mm for Body, 0.35mm for Cones & 0.35mm for Domes
70mm Necked-In
1.80Mpa
2.00Mpa
CMYK colors
0.23mm for Body, 0.43mm for Cones & 0.43mm for Domes


If you want to know more about the Empty Aerosol Tin Cans, please feel free to contact as belows.
